SJ-B Film Blowing Machine Set

This machine is suitable for blowing and making various plastic films such as LDPE, HDPE and linear LDPE films, which have been widely used for packing such civilian industrial products as foods, fruits, clothes, textiles and vest bags. use:Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.OPTIONAL EQUIPMENT: 1)AUTO LOAD 2)AIR COMPRESSOR 3)SPECIAL DIE 4)DIE ROTARY DEVICE 5)BOUBLE SIDES WINDER 6) UP AND DOWNMain Technical Variables:Model A50Diameter of screwφ50Rcduced diameter of film(mm)100-600Single-face Thickness of film(mm)0.01-0.10Max.Extrusion(Kg/h)35L/D26:1Power of main moto(kw)7.5Power of Tracion main moto(kw)0.75Heating Power(kw)11Outline diameter(L x W x H) (mm)4800 x 1900 x 4100Weight(T)1.5T
